Coatings & Laminations

Coatings and laminations explained

After printing, most packaging receives a coating or lamination to protect the print and set its look and feel. Coatings are liquids applied on press or in-line; laminations are thin films bonded to the surface. Choosing the right one affects durability, appearance, cost and recyclability.

Why packaging needs a protective finish

Printed packaging lives a hard life. Cartons rub against each other in shipping cases, mailers slide across conveyor belts, retail boxes are handled by dozens of shoppers, and gift boxes are opened, closed and stored. Uncoated ink can scuff, smudge, fade or pick up fingerprints and moisture. A coating or lamination is a thin protective layer that:

• Protects print from scuffs, abrasion and fingerprints
• Sets the visual character: glossy and vivid, satin and calm, or matte and modern
• Changes the feel in the hand, from slick to silky to velvety
• Adds some resistance to moisture and grease (laminations more than coatings)
• Prepares the surface for other finishes such as spot UV and foil

Choosing a finish is therefore both a design decision and a performance decision.

Coatings in detail

Aqueous coating

Aqueous coating is a clear, water-based coating applied in-line on the printing press, immediately after the inks. It dries quickly with heat and air, which keeps production fast.

• Looks: available in gloss, satin (dull) and matte versions
• Protection: good against light scuffing and fingerprints
• Recyclability: excellent; aqueous coatings are compatible with standard paper recycling
• Cost: low; often included as standard on printed cartons
• Best for: everyday retail cartons, food packaging (with suitable grades), mailers, any project where recyclability matters

UV coating

UV coating is a liquid that cures instantly to a hard, glass-like film under ultraviolet light. It can be applied overall (flood) or to selected areas (spot UV).

• Looks: very high gloss; matte UV is also available
• Protection: strong scratch and rub resistance
• Recyclability: generally accepted in paper recycling in normal amounts
• Cost: low to moderate
• Best for: high-gloss retail packaging and spot effects; see spot UV
• Watch-outs: can crack on folds of thick board if not scored correctly

Varnish

Varnish is an oil-based clear coating applied on press like an extra ink. It offers less protection than aqueous or UV but can be applied very precisely, including as a spot varnish or as a "satin" overall finish.

• Best for: subtle gloss/matte contrast effects, economical protection
• Watch-outs: can yellow slightly over time; slower drying

Specialty coatings

• Soft-touch coating: a liquid alternative to soft-touch film with a velvety feel; less durable than lamination but often better for recyclability
• Textured coatings: sand, leather or raised textures applied by screen or special plates
• Barrier coatings: water-based coatings that resist grease or moisture for food and cold-chain packaging
• Pearlescent or glitter coatings: add shimmer; check recyclability before using large areas

Laminations in detail

A lamination is a thin plastic film (commonly BOPP polypropylene, sometimes PET) bonded to the printed sheet with heat and adhesive. Laminations provide the highest level of protection and the richest finishes.

Gloss lamination

• Looks: high shine that deepens blacks and makes colors pop
• Protection: excellent against scuffs, moisture and tearing
• Best for: vivid photography, children's products, bold pop colors
• Watch-outs: shows fingerprints and reflections; glare under store lighting

Matte lamination

• Looks: smooth, non-reflective, sophisticated
• Protection: excellent
• Best for: premium cosmetics, electronics, modern minimal brands; the most popular lamination for rigid boxes
• Watch-outs: darkens and softens colors slightly; dark solid colors can show scuffs as shiny marks over time (choose anti-scuff matte films where available)

Soft-touch lamination

• Looks and feels: velvety, peach-skin texture that invites touch
• Best for: luxury cosmetics, fragrance, tech, gifts
• See our dedicated soft-touch lamination page

Specialty films

• Anti-scuff matte: a tougher matte film that resists burnishing marks on dark designs
• Holographic and metallic films: full-surface metallic effects; print white ink on top to control where the metal shows
• Linen and textured films: add a tactile pattern
• Sandy or gritty films: a tactile, unusual feel for niche brands

Coating vs. lamination: a direct comparison

One practical point often overlooked: laminations reduce fold cracking. Because the film stretches over the fold instead of breaking, dark designs on thick board often look better laminated than coated.

How finishes change color

Finishes alter how printed colors look:

• Gloss increases contrast and saturation; blacks look deeper.
• Matte reduces contrast; colors look slightly darker, softer and less saturated.
• Soft-touch has a strong muting effect, especially on bright colors and whites.
• Aqueous has a modest effect depending on the gloss level.

Always approve proofs and samples with the finish applied. If a specific brand color must match, tell us the finish so the color can be adjusted on press.

Combining coatings and laminations with other finishes

Food, cosmetics and regulated products

• Food: where packaging contacts food directly, coatings must be suitable for food contact. Many cartons use an aqueous coating outside and no coating on the food-contact side, or a specific barrier coating. Tell us how the food is packed.
• Cosmetics: laminations protect against oils and handling; check that finishes resist the products themselves (for example, oils from lotions).
• Frozen and chilled: moisture-resistant coatings or laminations help cartons survive condensation.

Sustainability: choosing the right level of protection

Laminations add a thin plastic layer. Many paper mills can process laminated board, removing the film as a reject, but acceptance varies. To balance protection and recyclability:

1. Use aqueous coatings wherever they give enough protection.
2. Reserve laminations for products that genuinely need high protection or premium feel.
3. Avoid full-surface metallic films on large boxes if recyclability is a priority.
4. Consider soft-touch coatings instead of soft-touch film for a recyclable velvet feel.
5. Tell customers how to dispose of packaging.

Cost of coatings and laminations

Laminations are priced by area, so large boxes cost more to laminate than small ones, but there is little setup. The finish cost tables on each product page show the estimated per-unit impact for a typical size.

How coatings and laminations are applied

In-line coating. Aqueous coatings and many varnishes are applied by a coating unit at the end of the printing press. The sheet is printed and coated in one pass, then dried with infrared heat and hot air. Because no extra pass is needed, in-line coating is fast and inexpensive.

UV curing. UV coatings are applied by a coating unit or screen, then pass under ultraviolet lamps that cure them in a fraction of a second. Spot UV is usually applied with a screen or a dedicated plate after printing.

Lamination. Lamination happens on a separate machine after printing. The film comes from a roll, adhesive is applied (or the film is pre-coated with heat-activated adhesive), and the film is pressed onto the printed sheet with heated rollers. The sheets are then trimmed. Because it is a separate step, lamination adds a little time and cost but provides the most durable finish.

Order of operations. For premium boxes the usual sequence is: print → laminate → spot UV → foil → emboss → die-cut. Each step relies on accurate registration so effects line up with the artwork.

Choosing a finish by product and channel

• Everyday retail and shipping: aqueous coating
• Vivid photography: gloss lamination or UV
• Modern, premium: matte lamination
• Luxury: soft-touch lamination
• Kraft and natural: uncoated or aqueous to keep the texture
• Food contact: specify food-safe coatings

Note: Laminations add a plastic film. If recyclability is a priority, choose aqueous coatings where protection needs allow.

Box StylesMailer BoxesSelf-locking corrugated mailers printed inside and out. The go-to box for DTC brands and subscriptions. Box StylesTuck End BoxesStraight and reverse tuck end cartons that open and reclose cleanly. Ideal for lightweight retail products. Box StylesRigid BoxesLuxury setup boxes made from thick greyboard wrapped in printed or specialty paper. Box StylesProduct BoxesPrinted paperboard boxes for retail shelves, gift sets and everyday products.

Dark designs and scuffing

Brands love deep black, navy and forest green packaging, but dark solid colors are the hardest to keep looking perfect. Scuffs from rubbing during shipping show as shiny marks on matte finishes and as dull scratches on gloss. To protect dark designs:

• Choose anti-scuff matte lamination where available.
• Pack cartons tightly in their shipping case so they cannot rub.
• Add slip sheets or tissue between premium boxes in transit.
• Consider a subtle pattern or texture in the design, which hides marks better than a perfectly flat color.
• For mailers, consider printing dark colors on the inside and keeping the outside lighter.

Finishes and print processes

Digital printing sometimes needs specific coatings or films that bond well to digital inks. We match the finish to the process automatically.

Specification checklist

• [ ] Finish type: aqueous, UV, varnish, gloss lamination, matte lamination, soft-touch, specialty
• [ ] Coverage: overall, outside only, inside too
• [ ] Additional effects: spot UV, foil, emboss
• [ ] Product contact: food, oils, moisture
• [ ] Recyclability priority: high, medium, low
• [ ] Design: dark solids? large flat colors?

Common mistakes

1. Choosing gloss for a premium minimal brand and finding it looks cheap under store lights.
2. Choosing soft-touch for an e-commerce box without an outer shipper, leading to marks in transit.
3. Not approving proofs with the finish, then being surprised by darker colors.
4. Laminating kraft, hiding the natural texture customers expect.
5. Ignoring recyclability when an aqueous coating would have been enough.

Coatings and laminations in one paragraph

Coatings are liquid finishes applied on press; laminations are thin films bonded after printing. Aqueous coatings are inexpensive and recyclable and suit most everyday packaging. UV and varnishes add gloss and spot effects. Gloss, matte and soft-touch laminations give the most protection and premium feel, and they reduce fold cracking on dark designs. Match the finish to your brand, your channel and your recyclability goals, and approve proofs with the finish in mind.

Aqueous, UV and varnish compared

The three main liquid coatings behave differently on the press and on the shelf.

Aqueous coating is the default protective layer for many cartons because it is economical, dries quickly and works well with recycling. UV coating gives more gloss and toughness. Varnish is useful for subtle spot effects.

Matte, satin and gloss: choosing the sheen

Sheen changes how a package feels as much as how it looks. Gloss makes colors vivid and images crisp, and suits playful, energetic brands. Matte reduces glare and feels modern and calm, and suits minimal, natural and luxury brands. Satin sits between the two. Matte surfaces show scuffs and fingerprints differently from gloss, so consider how the packaging will be handled. If you are unsure, ask for printed samples of the same artwork in each sheen.

Barrier coatings

Some coatings protect against more than scuffs. Barrier coatings resist grease, moisture or water, which matters for food packaging, cosmetics and products stored in humid conditions. Water-based barrier coatings are increasingly used as alternatives to plastic laminations, keeping cartons easier to recycle. Their performance varies, so test them with your product, especially for oily foods, frozen goods or products that may sweat.

Lamination films: gloss, matte, soft-touch and specialty

Laminations bond a thin film to the printed board. Gloss film gives deep, shiny color and strong protection. Matte film gives a smooth, low-glare finish. Soft-touch film adds a velvety feel. Specialty films include anti-scuff films that resist marking, metallic films that turn printed areas into metallic effects, and textured films that mimic linen or other surfaces. Laminations offer more protection than coatings and are common on rigid box wraps, premium cartons and mailers.

When protection is essential

Some packaging needs a protective finish more than others:

• Dark designs show scuffs easily and benefit from a coating or lamination.
• Shipping mailers rub against each other and against conveyors in transit.
• Retail cartons are handled by many shoppers.
• Products stored in humid or cold environments need moisture resistance.
• Packaging that customers keep, such as gift boxes, benefits from durable surfaces.

For lightly handled, short-life packaging, an aqueous coating may be enough.

Lamination on rigid box wraps

Rigid boxes are wrapped in thin printed paper. Laminating the paper before wrapping protects the print as it folds around corners and gives the finished box its texture and sheen. Without lamination, dark colors can crack at corners and edges. Matte and soft-touch laminations are the most popular for rigid boxes because they feel premium; gloss suits bright, playful designs.

Testing finishes

Before committing to a large run, test the finish with real handling. Rub the surface with a finger and a cloth, scratch lightly with a fingernail, and stack cartons and slide them against each other. Ship a few packed boxes through your carrier and inspect them on arrival. These simple tests reveal whether a finish is right for your packaging's journey.

Coatings and laminations for different packaging types

Coatings, laminations and recycling claims

If you make recyclability claims, consider how finishes affect them. Aqueous coatings are generally compatible with paper recycling. Plastic laminations add a non-paper layer, though laminated cartons are commonly accepted in paper recycling programs. Describe packaging accurately, and check guidance from recycling programs or label schemes when making claims.

Coatings FAQ for designers

Designers often ask whether to specify coatings in artwork. Coatings applied across the whole surface do not need artwork; spot coatings do. Indicate any areas to leave uncoated, such as glue flaps or areas for writing, so the coating does not interfere with adhesion or usability.

Worked example: protecting a dark mailer

A tech accessory brand shipped black mailers that arrived scuffed. The brand switched from an aqueous coating to an anti-scuff matte lamination and changed the outer design from solid black to a deep charcoal pattern. Scuffs became far less visible, the boxes looked premium in unboxing photos, and the slight extra cost per unit was offset by fewer complaints about damaged-looking packaging.

More coatings FAQ

Can I write on coated packaging?

Uncoated and aqueous-coated surfaces accept pens better than UV-coated or laminated surfaces. Leave areas uncoated if writing is needed.

Quick decision guide for protective finishes

How to brief us on coatings and laminations

Protective finishes are part of your box specification. Tell us:

• How the packaging travels. Retail shelf, parcel network or both.
• Look and feel. Gloss, matte, satin or soft-touch.
• Design colors. Dark designs need more scuff protection.
• Other finishes. Foil, spot UV or embossing.
• Sustainability goals. Coatings vs. laminations.

Send what you have, even if some answers are rough. Our specialists reply within one business day with recommendations, a price estimate and next steps, and every order includes free design help and a 3D proof before anything goes to production.

What matte lamination adds to popular box styles

Estimated unit prices from our published pricing model for each style at its most popular size, full-color print, delivered within the contiguous US. The last two columns show what matte lamination adds per box at 1,000 and 5,000 units; setup tooling is spread across the run, so the premium shrinks as quantity grows.

Estimates for planning. Your quote confirms the exact price for your size, coverage and artwork.

What gloss lamination adds to popular box styles

Estimated unit prices from our published pricing model for each style at its most popular size, full-color print, delivered within the contiguous US. The last two columns show what gloss lamination adds per box at 1,000 and 5,000 units; setup tooling is spread across the run, so the premium shrinks as quantity grows.

Estimates for planning. Your quote confirms the exact price for your size, coverage and artwork.

How to order coatings & laminations

1. 1Request a quote

   Tell us the style, size, quantity and artwork you have. Use the form or the live estimator.

2. 2Free design & dieline

   We send a dieline for your exact size, check your artwork and help with layout at no charge.

3. 3Approve your proof

   Review a digital 3D proof (and an optional physical sample) before anything is printed.

4. 4Production & QC

   Your boxes are printed, finished, die-cut and inspected against the approved proof.

5. 5Delivered to your door

   Shipped flat-packed with tracking to any address in the contiguous US.
